IS200ERRBG1ABA Mark VIe Control System
IS200ERRBG1ABA Product Introduction
Basic Information
Brand: GE (General Electric)
Model:IS200ERRBG1ABA
Part Number: IS200ERRBG1ABA
Series: Mark VIe Speedtronic Turbine Control System I/O Pack
Country of Origin: United States
Product Type: Discrete Input Module (Contact Input Module), also known as PDIA I/O Pack
Functional OverviewThe IS200ERRBG1ABA is a 24-channel discrete (digital) input module in the GE Mark VIe control system. Its primary function is to collect discrete signals (contact open/close signals) generated by field devices such as sensors,
switches, and relays, convert them into digital signals that can be recognized and processed by the PLC or control system CPU,
and transmit the processed data to the GE Speedtronic turbine control system or other control equipment, enabling automated control and monitoring. Key Technical Specifications
Rated Voltage: 24.0 VDC (Nominal)
Maximum Rated Voltage: 28.6 VDC
Maximum Rated Contact Input Voltage: 32 VDC
Number of Input Channels: 24 Discrete Inputs
Operating Temperature Range: -30°C to +65°C
Environmental Adaptability: Passes rigorous environmental testing, capable of long-term stable operation in harsh industrial environments Compatible Terminal Boards
The IS200ERRBG1ABA can be paired with a variety of GE terminal boards, including but not limited to:
IS200STCIH1A / IS200STCIH2A
IS200STCIH8A
IS200TBCIH2C / IS200TBCIH4C
IS400STCIH1A / IS400STCIH2A / IS400STCIH8A
IS400TBCIH2C Certifications and Safety
This module is UL certified and can be used in both hazardous and non-hazardous locations. The UL certification covers various classes and divisions, and relevant UL mark documents are available for reference.
The communication bus can be changed according to user needs without changing the communication interface. This is a flexible choice based on ABB’s unique FBP bus technology. Different bus protocols can be changed by simply changing FBP bus adapters of different types of buses (bus types) on the same FBP bus adapter (neutral bus interface). For example Profibus or DeviceNet. This change does not require the user to make any special settings. It only requires changing to the corresponding FBP bus adapter and making some simple configurations in the software. The control system automatically recognizes changes in the communication protocol of the connected electrical equipment. This brings convenience to users when changing between standard fieldbuses. ABB’s AC500 series PLC can also run as a fieldbus slave station through the FBP adapter.
image 3
3.2 Simplify the entire fieldbus
The FBP bus adapter can easily and quickly connect to any bus system to simplify the entire fieldbus. ABB is now able to offer a bus-independent interface plug-in, which means that suppliers no longer need to redesign their products for different target bus markets. Each automation device can be connected to the bus through the corresponding bus plug-in, and one bus protocol corresponds to one bus plug-in. For example, to connect a motor starter to the DeviceNet bus, you only need to connect the DeviceNet bus plug-in to a standard motor starter.
This fieldbus plug-in meets all electronic data transmission needs by converting data on the connected bus into a neutral data format recognized by standard automation devices and vice versa.
ABB’s motor controllers and motor starters are equipped with a bus-independent FBP interface. All installation engineers only need to hang the prepared FBP connection cable corresponding to the corresponding bus interface directly to the field bus.
The FBP fieldbus plug can complete the connection between some special switches and automation equipment and the process controller. The design of the plug-in is also very simple. One end is a universal interface that has nothing to do with the bus type, and the other end is an interface that conforms to a specific bus standard. The compact interface is equipped with an intelligent electronic conversion device, which can convert neutral device data into a language form that can be understood by buses such as AS-i or DeviceNet.
4. FBP bus adapter is used in hardware configuration of intelligent motor controller (UMC)
In order to better illustrate the flexible application of ABB FBP fieldbus adapter in intelligent motor controllers, we use ABB’s AC500 series programmable controller and Profibus bus adapter for illustration.
Application of ABB FBP bus adapter in intelligent motor controller 1:
Figure 4 Application of FBP bus adapter in smart motors
In Figure 4, the automation control management units (PLCs) use ABB’s AC500 series PM581 as the programmable controller CPU . The CPU has: LCD display, a set of operation buttons, an SD card expansion port and two integrated Serial communication port, CPU base plate integrates Ethernet interface , and retains CS31 communication interface, which has the characteristics of good compatibility with AC31 series PLC.
FBP fieldbus adapter: PDP22-FBP.xxx; related cables and accessories: PDA11-FBP.xxx and PDR11-FBP.150 terminating resistor . The PLC communication master station connects simply and quickly through the FBP bus adapter to the intelligent motor controller UMC22 with neutral interface, soft starter and other field devices, thereby achieving a seamless connection from the control layer to the field layer. FBP bus adapters are also widely used in situations where equipment is relatively scattered. Some sites are far apart, especially some on-site sites, which are more than 100 meters apart. Therefore, the transmission rates of all networks are set to the same to ensure reliable communication. In addition to distributed I/O , circuit breakers and sensors located at the production site, the bus network system of intelligent motor controllers and frequency converters is distributed in the motor control center (IMCC) room, which realizes centralized control of the motor and unified manage.
